Technical Package

Our technical team is our asset. We have executed jobs in earthquake and cyclone prone zones.


Material Specification

Material: Aluminum – Zinc Alloy Bare / Colour Coated Sheets – (Galvalume – An Alloy of 55% Aluminum & 43% Zinc)

Grade: ASTMA792 - Yield Strength : 300-350 MPA

Thickness: 0.7-1.6mm BMT (Base Metal Thickness)

Colour Coating: RMP, PVDF, SDP, SMP & HDP Coatings

Coating Grade: AZ150

(*-is trademark of Bluescope Steel Ltd.)
